CNG filling valves VM04 PICO

CNG filling valves VM04 PICO


CNG manual filling valves with PICO

Description

Tomasetto CNG manual filling valves VM04 are homologated in accordance with the European Regulation ECE R110.

CNG Manual Filling valves with PICO are provided with manual tap, discharge tap and are available with different types of connectors:

  • PICO New Zealand
  • PICO Brazil
  • PICO Argentina
  • Features & Options
TECHNICAL DATA

CNG FILLING VALVE VM04 WITH PICO
Material Hot forged brass CNC machined
Weight 0.43 kg
Type of product CNG manual filling valve
Max. working pressure 26.0 MPa
Working temperature -40°C / 120°C
Manual tap, min. area of gas flow 12.6 mm²
Manual tap, Tightening torque at 26 MPa 3 ± 0.5 Nm
Manual tap,Opening/closing angle 900° (±45°)
Non return valve yes
Outlet pipe connection M12x1 (upon request M14x1, 1/4" NPT, 1/8" NPT)
External pipe connection 1/2 G
Types of PICO New Zealand, Brazil, Argentina
